Technical characteristics:

Sampling is completed without residual liquid, safe and environmental protection

Sampling port directly welding in pipeline flow sampling medium, no waste of medium, without the medium of stasis, there is no need to circulating medium outlet pipe and adding air interface

High sampling accuracy of pipeline

The installation is simple, the installation cost is low, and no other connection or seal is required.

 It overcomes the disadvantages of high viscosity and easy coagulation, and the sampling is not accompanied by mild heating.

Controllable flow sampling, with cooling function, avoid splashing and scald

The operation is simple, the maintenance is convenient, the energy conservation effect is remarkable, the main body material are 304, 316, 316L,with the precision casting, the anticorrosion, the rust prevention ensures the sampling medium without pollution.            Beautiful appearance

Scope of application:

Suitable for all kinds of viscosity, no strong corrosive high temperature, flammable liquid medium sampling

Adaptation temperature: -196 ~ 550 degrees C

       Adaptation pressure: 0 ~ 6.8MPa
