The Technical Parameters

1. Working pressure ≤ 0.2Mpa

2. Operating temperature: 0 ℃ -80 ℃

3. Nominal cut water: 5m ³ / h, 10m ³ / h, 15m ³ / h, 20m ³ / h, 30m ³ / h, 60m ³ / h

4. cut water oil content: ≤ 80ppm

5. working medium: A type of light oil, B-type crude oil or heavy oil

6. Medium Density ρ20: ≤ 960kg / m³

7 .steam pressure: 0.1MPa ≤ P ≤ 1.0 MPa

     The Principle

     This product uses the principles of Archimedes, that leverage and pressure inside a container filled with liquid uniform principles, relying on a float buoyancy in the water medium is poor, so that it can float up and down movement, and by increasing the force of the amplification mechanism will make it float to obtain a larger buoyancy difference, as the power control drain valve opens, to cut the water and seal oil, and consequent continues to automatically separate the water.
